HUBER+SUHNER has pioneered multicoax solutions for applications up to 90 GHz
In a world where performance, speed and density matter, our multicoax connector solutions are the perfect fit.
The small form factor and outstanding electrical characteristics with highest repeatability combined with reliable mating and ease of use make MXP and MXPM an excellent solution for bench-top and system testing. Both high density cabling solutions can also be used as an interconnect within automated semiconductor test equipment.
The solderless compression mount multicoax connector MXPD70 engineered for optimal signal integrity in tight spaces, delivers a bandwidth of up to 70 GHz. Its innovative interface design ensures superior mechanical reliability and guarantees precise reproducibility of values, providing accurate and consistent results every time. The ultra-low profile rectangular version can easily be placed under a heater, very close to the chip, to minimize the lossy trace lengths.
Trust MXPD70 to elevate your testing capabilities, providing the performance and reliability essential for applications such as high-speed digital evaluation and reference boards, test and characterization boards, and system testing.
Features
Superior signal integrity up to 70 GHz, suitable for 112 Gbps data analysis
3.4 mm / 0.134 inch pitch signal-to-signal
Identical layouts for straight and right angle versions
No hard gold plating required on PCB
Swivel-mounted interface protection
MXPM is the pioneering multicoax solution that supports up to 90 GHz/PAM4, 224 Gbps. By offering a high density pitch of 2.54 mm (0.1 inch), the MXPM line guarantees a hassle-free experience with its user-friendly magnet-mount connection, delivering performance, reliability and values.
Features
Operating range at up to 90 GHz
Broadband characteristic
1×8 and 2×8 ganged solutions available
2.54 mm (0.1 in.) pitch centre-to-centre
Standard phase matching down to +/- 1 ps
Magnetic locking mechanism
Automatic interface protection
Cost efficient PCB sockets
Highly flexible and ultra-stable Multiflex cable
The MXP product line offers a large selection of bandwidths: MXP50 (50 GHz), MXP40 (40 GHz) and MXP18 (18 GHz) that cover data rate requirements up to 56Gbps and beyond. The entire MXP family comes with the highly flexible and ultra-stable MULTIFLEX cable as a standard.
Features
Operating range at up to 50 GHz
Broadband characteristic
1×8 and 2×8 ganged solutions available
4 mm (0.16 in.) pitch centre-to-centre
Standard absolute phase matching down to +/- 2 ps
Highest density – lowest loss
Slide-on mating – no threading
Highly flexible and ultra-stable MULTIFLEX cable
Extensive technical support
